Slurry sumps can be a headache. Pumps wear hard and fast. They need service between maintenance intervals. And to make matters worse, the sumps fill up with sediment.
Cantilever pumps are often not up to the task. We know, because that’s when Xylem gets the call: When an installed slurry pump is struggling to do its job.
With a wide range of pumps, plus a flexible modular system, Flygt can supply exactly the right pump for any application.
The Flygt H 5100 slurry pump is different. Following a planned maintenance schedule, this Flygt pump can work in even the coarsest, heaviest slurries and keep sumps solids free.
| MODEL | 5100 211 | 5100 251 | 5100 300 | 5150 300 | 5150 350 | 5520 | 5530 | 5570 600 | 5570 700 | |
| Voltage | V | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 |
| Rating,hp | kW | 12-20(9-15) | 25-34(19-25) | 35-70 (26-56) | 45-70 (26-56) | 85-105 (63-78) | 5(3.7) | 10 (7.5) | 90-160 (67-119) | 150-335 (112-250) |
| Rated current | A | 21-26 | 31-40 | 43-80 | 43-80 | 101-121 | 7.4 | 15 | 115-190 | 190-385 |
| Discharge Ø | in | 4″ | 4″ | 4″ | 4″ | 6″ | 4″ | 6″ | 8″ | 8″ |
| Strainer hole,in | mm | 1 3/16 (30) | 1 3/16 (30) | 1 3/16″ (30) | 1 3/16″ (30) | 1 3/8″ (36) | 3/4 ” (20) | 1 3/16″ (30) | 1 3/16″ (30) | 1 3/16″ (30) |
| Max height,ft in | mm | 3″3″ (978) | 3’8″ (1124) | 4’3″ (1296) | 4’8″ (1124) | 5′ (1537) | 2’9″ (848) | 2’9″ (848) | 6’9″ (2868) | 7’7″ (2312) |
| Max width,in | mm | 21 1/2″ (547) | 21 1/2″ (547) | 23″ (595) | 34″ (875) | 34″ (875) | 19″ (478) | 25″ (632) | 48″ (1225) | 48″ (1225) |
| Weight,lbe | kg | 474 (215) | 611 (277) | 1290*585) | 1290 (585) | 1800 (817) | 269 (122) | 448 (203) | 2976 (1350) | 4409 (2000) |
| Internal cooling | . | . | . | . | . | . | . | . | . | |
| External cooling | . | . | . | . | . | . | . | . | . | |
| Agitator | . | . | . | . | . | . | . | . | . | |
| Warm liquid 70°C | . | . | . | . | . | . | . | . | . | |
| Ex version | . | . | . | . | . | . | . | . | . | |
